Crystal Series Solar LED Street Light
l Die-casting aluminum material, better heat dissipation performance.
l Philips Lumileds LED chips, >160lm/w for complete LED light source.
l Higher conversion rate is more than 21% for monocrystalline solar panel.
l PWM solar controller, manage the charging and discharging for complete solar system.
l Most reliable quality for LiFePO4 lithium battery and longer lifespan, deep cycle times is >2000.
l Easy for installation, free for maintenance, more cost-effective.
- Parameters
l Die-casting aluminum material, better heat dissipation performance.
l Philips Lumileds LED chips, >160lm/w for complete LED light source.
l Higher conversion rate is more than 21% for monocrystalline solar panel.
l PWM solar controller, manage the charging and discharging for complete solar system.
l Most reliable quality for LiFePO4 lithium battery and longer lifespan, deep cycle times is >2000.
l Easy for installation, free for maintenance, more cost-effective.
Features
l Innovative design and compact structures.
l Die-casting aluminum material, better heat dissipation performance.
l Philips Lumileds LED chips, >160lm/w for complete LED light source.
l Higher conversion rate is more than 20% for monocrystalline solar panel.
l PWM solar controller, manage the charging and discharging for complete solar system.
l Most reliable quality for LiFePO4 lithium battery and longer lifespan, deep cycle times is >2000.
l Easy for installation, free for maintenance, more cost-effective.
Application
Widely use to urban road, village, streets, garden, yard, parking lot,.etc and other outdoor lighting applications.
Model | Solar Panel Power | Lithium battery capacity | Luminous flux (lm) | CCT | CRI (Ra) | Beam Angle | Installation height | Installation distance | Work hours (can reset up) | IP grade | Product dimension |
G-CST25 | 25 W | 3.2/20Ah | 1200 | 5700K | 80 | 120*120 | 3-4m | 10-12m | 8-10 hrs | 65 | 64*30cm |
G-CST35 | 35 W | 3.2/30Ah | 1800 | 5700K | 80 | 120*120 | 3-4m | 12-15m | 8-10 hrs | 65 | 64*30cm |
G-CST40 | 40 W | 3.2/40Ah | 2400 | 5700K | 80 | 120*120 | 5-6m | 15-18m | 8-10 hrs | 65 | 64*30cm |
Carton size: 78*41*44 cm.
Packing way: 1set / carton or 2 set/carton are available.
Model | Length (cm) | Width (cm) | Height (cm) | Net Weight (KG) /SET | Gross Weight (KG) / SET | SET/CTN | Net Weight (KG) / 2 Sets | Gross Weight (KG) / 2 Sets | SET/CTN |
G-CST25 | 78 | 41 | 44 | 6.2 | 8.1 | 1 | 12.4 | 14.3 | 2 |
G-CST35 | 78 | 41 | 44 | 6.4 | 8.8 | 1 | 12.8 | 15.5 | 2 |
G-CST40 | 78 | 41 | 44 | 7.2 | 9.5 | 1 | 14.4 | 16.65 | 2 |
